Battery Powered Electromagnetic Flow Meter

Share to:
  • long life span, standard battery can work for 3-6 years.
  • Dual power supply
  • 12-24vdc power supply, enabling users to have a variety of
  • power options;
  • Multiple network interfaces: W803 has GPRS, RS485, HART and other network
  • Multiple work mode: W803E has ‘Flow Only’ mode, ‘Flow + Pressure’ mode, ‘Flow +Temperature’ mode
Availability:
Quantity:


Battery-Powered Electromagnetic Flow Meter Introduction

Battery-powered magnetic flow meter can be used in remote area where don't have power grid. It is widely used for all conductive liquids in every industry, such as water, acid, alkali, milk, slurry etc. Since founded in 2005, We have been focused in magnetic flow meter manufacturing for more than 15 years. More than 600 thousand mag meters had been provided to clients all over the world for different work conditions.

Battery Operated Flow Meter is a lithium battery powered electromagnetic flow meter developed on the basis of electromagnetic flow meter. The battery-powered electromagnetic flowmeter uses a specially designed sensor excitation system and a high-performance lithium battery power supply system. Designed specifically for the water industry. Satisfy urban water supply to ensure accurate water fee calculation. It is widely used in the workplace without power supply. Such as: urban water supply, heating, sewage treatment, water administration and water resources, water conservancy projects and other industries.

Battery-Powered Electromagnetic Flow Meter Features




    • Large-screen clear LCD display: clear and fast data display, ensuring fast reading of data

    • Full digital signal processing, stable work, high measurement accuracy, strong anti-interference ability

    • Three-electrode measurement, more accurate than general two-electrode measurement

    • The service life is up to 3-5 years

    • Automatic two-way flow measurement, on-site instantaneous flow, forward and reverse cumulative total, pressure (special customization) display

    • Self-diagnosis fault alarm and GSM/GPRS data wireless remote transmission function

    • Through the GSM/GPRS remote management software system, functions such as wireless remote transmission, storage and data analysis of flow data can be realized.

    • The meter adopts piecewise linear correction, so that it can ensure the accuracy requirements in the large, medium and small flow measurement.

Battery-Powered Electromagnetic Flow Meter Specification

SizeDN3-DN3000mm
Nominal Pressure0.6-1.6Mpa(2.5Mpa/4.0Mpa/6.4Mpa...Max 42Mpa)
Accuracy+/-0.5%(Standard)
+/-0.3% or +/-0.2%(Optional)
LinerPTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
ElectrodeSUS316L, Hastelloy B, Hastelloy C
Titanium, Tantalum, Platinium-iridium
Structure TypeIntegral type, remote type, submersible type, ex-proof type
Medium Temperature-20~+60 degC(Integral type)
Remote type(Neoprene,Hard Rubber,Polyurethane,EPDM) -10~+80degC
Remote type(PTFE/PFA/FEP) -10~+160degC
Ambient Temperature-20~+60deg C
Ambient Humidity5-100%RH(relative humidity)
Measuring RangeMax 15m/s
Conductivity>5us/cm
Protection ClassIP65(Standard); IP68(Optional for remote type)
Process ConnectionFlange (Standard), Wafer, Thread, Tri-clamp etc (Optional)

Output Signal4-20mA/Pulse
CommunicationRS485(Standard), HART(Optional),GPRS/GSM (Optional)
Power SupplyAC220V (can be used for AC85-250V)
DC24V (can be used for DC20-36V)
DC12V (optional), Battery Powered 3.6V (optional)
Power Consumption<20W
AlarmUpper Limit Alarm / Lower Limit Alarm
Self-diagnosisEmpty Pipe Alarm, Exciting Alarm
Explosion ProofATEX

Battery Powered Electromagnetic Flow Meter Selection Guide

HILDxxxxxxxxxxx
CaliberDN3mm-DN3000mm








Nominal Pressure0.6Mpa1
1.0Mpa2
1.6Mpa3
4.0Mpa4
Other5
Connection ModeFlange connection1
Clamp connection2
Sanitary connection3
Liner MaterialPTFE1
PFA2
Neoprenen3
Polyurethane4
Ceramic5
Electrode Material316L1
Hastelloy B2
Hastelloy C3
Titanium4
Platinum-iridium5
Tantalum6
Stainless steel covered with tungsten carbide7
Structure TypeIntegral type1
Remote type2
Remote type immerse3
Integral type Ex-proof4
Remote type Ex-proof5
Power220VAC 50HzE
24VDCG
Output communicationFlow volume 4-20mADC/pulseA
Flow volume 4-20mADC/RS232C communicationB
Flow volume 4-20mADC/RS485 communicationC
Flow volume HART output/with communicationD
Converter FigureSquareA
CircularB



-Manuals

Battery-Powered Electromagnetic Flow Meter

-Data sheet


Battery-Powered Electromagnetic Flow Meter Application

Electromagnetic flow meter is widely used in water treatment, food industry, pharmaceutical, petrochemical, paper mill, chemical monitoring etc.
In the metallurgical industry, it is often used to control the flow of cooling water for continuous steel casting, continuous steel rolling, and steel-making electric furnaces;
In the field of water supply and drainage in public utilities, electromagnetic flow meters are often used for the transfer measurement of finished product water and raw water in water plants;
In the pulp process of the paper industry, electromagnetic flow meters are involved in the measurement of the flow of grinding pulp, water, acid, and alkali;
In the coal industry, measuring coal washing and pipeline hydraulic conveying coal slurry.
For food and beverage industries, it is used for beer and beverage filling measurement.
For chemical and petrochemical industries, it is used to measure corrosive liquids, such as acids and alkalis etc.
