Rosemount 5300 Guided Wave Radar Level Transmitter

Share to:
  • 5301 for level of liquids or submerged interfaces
  • 5302 for level and interface liquids
  • 5303 for level of solids
  • Time domain reflectometry (TDR) measurement principle
  • SST, Monel, Hastelloy or PTFE-covered SST probe materials
  • 4-20mA with superimposed HART or Fieldbus communication output
  • Up to 752°F process temperature
  • Up to 5000 psi (345 bar) process pressure at 100°F
  • Intrinsic safety or Explosion/Flameproof Ex-Approvals
Availability:
Quantity:

Rosemount 5300 Guided Wave Radar Level Transmitter Introduction

Rosemount 5300 Level Transmitter is ideal for challenging measurements on liquids, slurries, and solids, offering state of the art reliability and safety features in level and interface applications. Rosemount 5300 offers several advantages such as easy installation, no need for calibration, and is unaffected by process conditions. Also, it is SIL 2 certified making it your first choice for safety applications. It has a robust construction and features powerful built-in diagnostics allowing you to focus on the essential part - your plant.

Rosemount 5300 Series level transmitter is our premium 2-wire guided wave radar for challenging level and interface measurements on liquids, slurries and solids. It is everything you would expect from a best-in-class process radar - superior reliability, state-of-the-art safety features, effortless handling, and unlimited connectivity.


Rosemount 5300 Guided Wave Radar Level Transmitter Feature


    • Direct Switch Technology gives increased sensitivity, high reliability, and long measurement ranges

    • Signal Quality Metrics gives you the ability to work proactively with your level instrumentation

    • Probe End Projection offers greater level measurement reliability

    • Dynamic Vapor Compensation for improved plant heat rate

    • Verification reflector for remote proof-testing and unique level transmitter verification

    • Ultra-thin layer detection through Peak-in-Peak technology


Rosemount 5300 Guided Wave Radar Level Transmitter Specification


    • Accuracy

      ± 0.12 in. (3 mm)

    • Repeatability

      ± 0.04 in. (1 mm)

    • Measurement Range

      Up to 164 ft (50 m)

    • Operating Pressure

      Full vacuum to 5000 psi (Full vacuum to 345 bar)

    • Operating Temperature

      -320 to 752 °F (-196 to 400 °C)

    • Communication Protocol

      4-20 mA/HART™, Foundation™ Fieldbus, Modbus™

    • Safety

      SIL 2 IEC 61508 certification
      TÜV tested and WHG approved for overfill prevention
      Remote proof-test capabilities through verification reflector

    • Diagnostics

      Enhanced diagnostics enabling proactive maintenance

    • Probe Types

      Rigid single lead, Segmented single lead, Flexible single lead, Rigid twin lead, Flexible twin lead, Coaxial and large coaxial, PTFE coated probes, Vapor probe

    • Warranty

      Up to five years
