Horizontal Split Case Fire Pump

Share to:
  • Outlet: DN80~1000mm
  • Flow rate: 100m3/h~11600m3/h
  • Head: 10m~200m
  • Speed: 550RPM-2150RPM
  • Power: 30HP~2500HP
  • Solid passing: ≤80mg/L
  • Driven: Electric Motor or Diesel Engine
Availability:
Quantity:

Horizontal Split Case Fire Pump Introduction

Horizontal split case pump is a unique type of centrifugal pump whose casing is divided into two distinct chambers, which is different from inline or end suction pumps that are assembled with the suction nozzle, discharge nozzle, and casing in one chamber.

Horizontal Split Case Fire Pump Feature

CHARACTERISTICS
  • Compact design and efficient operation

  • Shaft sleeve to protect the shaft against corrosion and wear

  • Interchangeable radial and thrust bearings with grease lubrication are guaranteed

  • Enclosed, double suction impeller, casted in one-piece and balanced to minimize thrust and ensure longer bearing life

  • Available with electric or diesel drive

BENEFITS
  • Ease of installation and maintenance

  • Wide range of applications

  • Construction materials for seawater service are available

DESIGN FEATURES
  • NFPA-20 design

  • UL-448 listed

  • FM-1311 approved

Reliability and Security

  • 21 CFR Part 11 compliance with an advanced security function option [R4]

  • Dust- and splash-proof front panel (IP65, NEMA4 compliant)

  • Highly reliable internal memory with error-correction function

  • Front panel door lock and login function


Horizontal Split Case Fire Pump Specification

mpellerSS304,SS316,Copper,HT200
Pump SealingPacking seal,Mechanical seal
Capacity Range126m3/h~8520m3/h
Head Range8m~140m
Inlet/Outlet diameter6"(150mm)~32"(800mm)
Rotary Speed1450rmp/2950rpm/585rpm/730rpm/970rpm
NPSH(r)2.5m~7.5m
Pump Parts

Casing,Pump cover,Impeller,Shaft, Double suction sealing ring

Shaft sleeve,Bearing etc

Certificate

ISO9001:2008,CE,TUV

-Manuals

Horizontal Split Case Fire Pump

-Data sheet


Horizontal Split Case Fire Pump Application

Horizontal split fire pump is one of the most popular pumps used in building application due to its range of flow and pressures that falls in line with most buildings. Horizontal split-case pumps are characterized by a housing that is split in half and bolted together
